PROCON®
Series 2 pumps have the
same features as the Series
1 except they do not have the
integral strainer. Series 1, 2,
and 3 are available in 11 flow
rates: 15, 25, 35, 50, 60, 70,
80, 100, 110, 125 and 140
gallons per hour at 250 psi.
PROCON®
Series 3 pumps boast all
the unique features of other
PROCON® pumps. Because
the pump body and all the
metal parts are made from
stainless steel, the Series 3
is well suited for pumping a
variety of fluids not suitable
with brass.
PROCON®
Series 4 & 5 pumps
are designed and built to
meet your needs for flow
rates ranging from 115 – 330
gallons per hour at 250 psi.
These PROCON® pumps
maintain all the quality
features and construction of
our Series 1, 2, & 3 pumps.
PROCON®
Series 6 pumps are
designed and built to meet
your needs for higher flows.
The flow rate capacity for this
pump ranges from 300 to 660
gallons per hour at 250 psi.
This series pump is available
only in bolt-on style.
Series 2 – Brass Pumps – 3/8″ NPT Ports; Clamp-on
| Part # | Description | 1+ | 4+ | 12+ | 24+ | |
| 112A015F11XX | 15 GPH NSF BRASS PUMP; W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 112A025F11XX | 25 GPH NSF BRASS PUMP; W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 102A035F11XX | 35 GPH BRASS PUMP; W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 112A035F11XX | 35 GPH NSF BRASS PUMP; W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 112A050F11XX | 50 GPH BRASS PUMP; W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 102A070F11XX | 70 GPH BRASS PUMP; W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 102A080F11BA225 | 80 GPH BRASS PUMP; 225 PSI | $70.82 | $66.10 | $61.38 | $58.55 | |
| 102A080F11XX | 80 GPH BRASS PUMP; W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 112A080F11XX | 80 GPH NSF BRASS PUMP; W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 102A100F11XX | 100 GPH BRASS PUMP; W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 112A100F11AA200 | 100 GPH NSF BRASS PUMP; 200 PSI | $70.82 | $66.10 | $61.38 | $58.55 | |
| 112A100F11AA250 | 100 GPH NSF BRASS PUMP; 250 PSI | $70.82 | $66.10 | $61.38 | $58.55 | |
| 102A125F11XX | 125 GPH BRASS PUMP: W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 112A125F11AA190 | 125 GPH NSF BRASS PUMP; 190 PSI | $70.82 | $66.10 | $61.38 | $58.55 | |
| 112A125F11XX | 125 GPH NSF BRASS PUMP; W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 | |
| 102A140F11BA225 | 140 GPH BRASS PUMP; 225 PSI | $70.82 | $66.10 | $61.38 | $58.55 | |
| 112A140F11XX | 140 GPH NSF BRASS PUMP: W/O RELIEF | $70.82 | $66.10 | $61.38 | $58.55 |
Series 3 – Stainless Steel Pumps – 3/8″ NPT Ports; Clamp-on
| Part # | Description | 1+ | 4+ | 12+ | 24+ | |
| 103A035F31BA170 | 35 GPH SS PUMP: 170 PSI | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103A035F31BA225 | 35 GPH SS PUMP: 225 PSI | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103A035F31XX | 35 GPH SS PUMP: W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 113A035F31XX | 35 GPH NSF SS PUMP; W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103A050F31XX | 50 GPH SS PUMP: W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 113A050F31XX | 50 GPH NSF SS PUMP; W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103A070F31XX | 70 GPH SS PUMP: W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103A080F31BA200 | 80 GPH SS PUMP: 200 PSI | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103A080F31XX | 80 GPH SS PUMP: W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 113A080F11AA200 | 80 GPH NSF SS PUMP: 200 PSI | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103A100F31BA170 | 100 GPH SS PUMP; 170 PSI | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103B100F31BA170 | 100 GPH SS PUMP; 170PSI | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103B100F31BA200 | 100 GPH SS PUMP; 200 PSI | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103A100F31XX | 100 GPH SS PUMP; W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103B100F31XX | 100 GPH SS PUMP; W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 113A100F31XX | 100 GPH NSF SS PUMP; W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 113B100F31BA225 | 100 GPH NSF SS PUMP: 225 PSI | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103A125F31BA170 | 125 GPH SS PUMP; 170 PSI | $141.96 | $132.50 | $123.04 | $117.36 | |
| 113A125F31XX | 125 GPH SS PUMP: W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 103B125F31XX | 125 GPH SS PUMP; W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 | |
| 113A125F31XX | 125 GPH NSF SS PUMP; W/O RELIEF | $141.96 | $132.50 | $123.04 | $117.36 |
Series 4 – Brass Pumps – 1/2″ NPT Ports; Clamp-on
| Part # | Description | 1+ | 4+ | 9+ | 18+ | |
| 104A140F11XX | 140 GPH BRASS PUMP: W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104B140F31BA200 | 140 GPH BRASS PUMP; 200 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104B140F11AA225 | 140 GPH BRASS PUMP; 225 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104B165F11XX | 165 GPH BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104B165F11BA225 | 165 GPH BRASS PUMP; 225 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114B165F11AA250 | 165 GPH NSF BRASS PUMP; 250 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114B165F11XX | 165 GPH NSF BRASS PUMP: W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114B165F31XX | 165 GPH NSF BRASS PUMP: W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104B190F11BA225 | 190 GPH BRASS PUMP; 225 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104B190F11XX | 190 GPH BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114B190F11AA250 | 190 GPH NSF BRASS PUMP; 250 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114B190F31XX | 190 GPH NSF BRASS PUMP: W/O RELIEF | $142.15 | $132.68 | $123.20 | $117.51 | |
| 104B215F11BA225 | 215 GPH BRASS PUMP; 225 PSI | $142.15 | $132.68 | $123.20 | $117.51 | |
| 114B215F11BA250 | 215 GPH NSF BRASS PUMP; 250 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104B240F11BA225 | 240 GPH BRASS PUMP; 225 PSI | $142.15 | $132.68 | $123.20 | $117.51 | |
| 114B240F11XX | 240 GPH BRASS PUMP; W/O RELIEF | $142.15 | $132.68 | $123.20 | $117.51 | |
| 114B240F11XX | 240 GPH NSF BRASS PUMP: W/O RELIEF | $142.15 | $132.68 | $123.20 | $117.51 | |
| 114B240F31XX | 240 GPH NSF BRASS PUMP: W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104B265F11XX | 265 GPH BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114B265F11BA250 | 265 GPH NSF BRASS PUMP; 250 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114B330F31XX | 330 GPH NSF BRASS PUMP: W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 |
Series 4 – Brass Pumps – 1/2″ NPT Ports; Bolt-on
| Part # | Description | 1+ | 4+ | 9+ | 18+ | |
| 104E140F11XX | 140 GPH BRASS PUMP: W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114E140F31XX | 140 GPH NSF BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E165F11AA170 | 165 GPH BRASS PUMP; 170 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E165F11BA225 | 165 GPH BRASS PUMP; 225 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E165F11XX | 165 GPH BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114E165F31XX | 165 GPH NSF BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E190F11XX | 190 GPH BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114E190F31XX | 190 GPH NSF BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E215F11BA250 | 215 GPH BRASS PUMP; 250 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E215F11XX | 215 GPH BRASS PUMP: W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E240F11BA225 | 240 GPH BRASS PUMP; 225 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E240F11XX | 240 GPH BRASS PUMP: W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114E240F11XX | 240 GPH NSF BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114E240F31XX | 240 GPH NSF BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E265F11AA200 | 265 GPH BRASS PUMP; 200 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E265F11AA225 | 265 GPH BRASS PUMP; 225 PSI | $142.16 | $132.68 | $123.21 | $117.52 | |
| 104E330F11XX | 330 GPH BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114E330F11XX | 330 GPH NSF BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 | |
| 114E330F31XX | 330 GPH NSF BRASS PUMP; W/O RELIEF | $142.16 | $132.68 | $123.21 | $117.52 |
Series 5 – Stainless Steel Pumps – 1/2″ NPT Ports; Clamp-on
| Part # | Description | 1+ | 4+ | 9+ | 18+ | |
| 105B140F31BA200 | 140 GPH SS PUMP; 200 PSI | $247.80 | $231.28 | $214.76 | $204.85 | |
| 105A165F31XX | 165 GPH SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 105B165F31XX | 165 GPH SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 105B165F31BA220 | 165 GPH SS PUMP; 220 PSI | $247.80 | $231.28 | $214.76 | $204.85 | |
| 105B165F31BA250 | 165 GPH SS PUMP; 250 PSI | $247.80 | $231.28 | $214.76 | $204.85 | |
| 115B165F31XX | 165 GPH NSF SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 105B190F31XX | 190 GPH SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 115B240F31BA170 | 240 GPH NSF SS PUMP; 170 PSI | $247.80 | $231.28 | $214.76 | $204.85 | |
| 115B240F31XX | 240 GPH NSF SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 115B330F31XX | 330 GPH NSF SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 |
Series 5 – Stainless Steel Pumps – 1/2″ NPT Ports; Bolt-on
| Part # | Description | 1+ | 4+ | 9+ | 18+ | |
| 105E115F31XX | 115 GPH SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 105E165F31XX | 165 GPH SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 105E215F31XX | 215 GPH SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 115E240F31XX | 240 GPH SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 115E240F31XX | 240 GPH NSF SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 105E330F31XX | 330 GPH SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 | |
| 115E330F31XX | 330 GPH NSF SS PUMP; W/O RELIEF | $247.80 | $231.28 | $214.76 | $204.85 |
Series 6 – Stainless Steel Pumps – 1″ NPT Ports; Bolt-on
| Part # | Description | 1+ | 2+ | 4+ | 8+ | |
| 116N300F11XX250 | 300 GPH NSF SS PUMP; W/O RELIEF | $663.85 | $619.60 | $575.34 | $548.79 | |
| 106N360F11XX | 360 GPH SS PUMP; W/O RELIEF | $663.85 | $619.60 | $575.34 | $548.79 | |
| 106N480F11XX | 480 GPH SS PUMP; W/O RELIEF | $663.85 | $619.60 | $575.34 | $548.79 | |
| 106N540F11XX | 540 GPH SS PUMP; W/O RELIEF | $663.85 | $619.60 | $575.34 | $548.79 | |
| 116N540F11XX | 540 GPH NSF S.S.PUMP; W/O RELIEF | $663.85 | $619.60 | $575.34 | $548.79 | |
| 106N600F11XX | 600 GPH SS PUMP; W/O RELIEF | $663.85 | $619.60 | $575.34 | $548.79 | |
| 106N660F11XX | 660 GPH SS PUMP; W/O RELIEF | $663.85 | $619.60 | $575.34 | $548.79 | |
| 116N660F11XX | 660 GPH NSF S.S. PUMP; W/O RELIEF | $663.86 | $619.60 | $575.35 | $548.79 |
Accessories
| Part # | Description | 1+ | 5+ | 10+ | 25+ | |
| 1113 | PROCON PUMP V-BAND CLAMP | $1.61 | $1.50 | $1.40 | $1.33 | |
| 1143 | COUPLING; SLOTTED ROTOR C/O | $4.58 | $4.27 | $3.97 | $3.79 | |
| 3045 | 3 PIECE DRIVE SHAFT COUPL; 5/8″ BOLT | $23.89 | $22.30 | $20.71 | $19.75 | |
| 3206 | PROCON 3600 COUPLING,5/8″ X 7/8″ | $49.85 | $46.53 | $43.20 | $41.21 | |
| 3206-1 | PROCON 3600 COUPLING,5/8″ X 5/8″ | $49.85 | $46.53 | $43.20 | $41.21 | |
| 3207-56C | PROCON FRAME ADAPTER | $48.26 | $45.04 | $41.83 | $39.90 | |
| 3208 | PROCON SHAFT KEY | $.24 | $.22 | $.21 | $.20 | |
| 3216 | PROCON FASTENERS | $1.53 | $1.43 | $1.33 | $1.27 | |
| 1048-1C | 56C FRAME MOTOR ADAPTER | $38.13 | $35.59 | $33.05 | $31.53 |
(Bolt-on 56C Frame mount) (Clamp-on 48YZ Frame mount)
